| Parameter | Wireless Mode | ||
|---|---|---|---|
| Operation Mode | Wireless Mode In addition to wireless operation, it also supports wired connection to a computer. | ||
| Fine Scan | 7 Parallel Blue Laser Lines | ||
| Scanning Mode | Laser Scanning Mode | 7 Cross Laser Scanning Mode | Infrared Scanning Mode |
| Light Source Type | 38 blue cross laser lines | 7 parallel blue laser lines | Infrared VCSEL Light Source |
| Single Point Accuracy | 0.05 mm - 10 mm | 0.2 mm - 10 mm | |
| Scanning Speed | 4,400,000 points/s | 940,000 points/s | 1,600,000 points/s |
| Working Distance | 170 mm -550 mm | 160 mm -1500 mm | |
| Alignment Mode | Feature/Marker/Geometry | Feature / Marker / Geometry /Texture/ Hybrid Alignment | |
| Minimum Point Distance | Up to 0.04 mm | ||
| Volumetric Accuracy | Up to 0.04 mm +0.06 mm/m | ||
| Texture Camera Resolution | 5.0 Megapixels | ||
| Data Output Format | .PLY, .STL, .OBJ, .ASC, .3MF | ||
| Laser Safety Class | Class II | ||
| Hardware Configuration | CPU: 8-core, 2.4GHz; 1TB SSD (Solid-state drive); 32GB DDR5 (Dual channel); 6.4-inch 2K AMOLED Touchscreen | ||
| Operating Temperature | -10°C-40°C | ||
| Certifications | CE, FCC, ROHS, WEEE, FDA, SRRC, IP50 | ||
| Recommended Computer Configuration | Windows 10/11, 64-bit; GPU: NVIDIA RTX 3060 or higher; VRAM = 8GB; CPU: i7-13700H or higher; RAM ≥ 64GB | ||
| Power Supply Standard | Built-in 7550mAh rechargeable battery (including spare battery); USB Type-Cinterface; supports 60W PD 3.0 fast charging | ||
| Device Dimensions | 233 mm x 180 mm x 72.8 mm (L x W x H) | ||
| Device Weight | 870 g (including battery and integrated display) | ||
